Lockwood 208/209 Series Push and Pull Plates
The 208/209 Series Door Furniture are 2mm thick stainless steel or brass plates with 10mm radius corners. Concealed fixed plates have studs with internal threads located in each corner, visible plates have corresponding countersunk holes and are fixed back to back through the door.
Application
Designed for use with 3570 Series Mortice Locks.
Lockwood 208/209 Series Push and Pull Plates
Materials
Stainless steel.Door Thickness
35 to 45mm standard. For doors 45 to 55mm thick, specify long fixing screws SP2000-208.Finishes
Standard
- Satin Stainless Steel SS
Non Standard
- Powdercoat PC
- Polished Stainless Steel PS
- Marine Grade MG
Dimensions
324 x 162 x 2mm.Description (Trade Pack) Part number Square Corner Plate Size 324mm x 162mm x 2mm - External Plain Push Plate 20807NNSS Square Corner Plate Size 324mm x 162mm x 2mm - Internal Plain Push Plate 20907NNSS Square Corner Plate Size 324mm x 162mm x 2mm - External Push Plate With Cyl Hole 20800NALSS 20800NARSS Square Corner Plate Size 324mm x 162mm x 2mm - Internal Push Plate With Cyl Hole 20900NALSS 20900NARSS Square Corner Plate Size 324mm x 162mm x 2mm - External Plain Plate With Pull Handle 267 X 17.5mm 20824NN/P4SS Square Corner Plate Size 324mm x 162mm x 2mm - Internal Plain Plate With Pull Handle 267 X 17.5mm 20924NN/P4SS Square Corner Plate Size 324mm x 162mm x 2mm - External Plate With Oval Cyl Hole & Pull Handle 267 X 17.5mm 20825NA/P4LSS 20825NA/P4RSS Square Corner Plate Size 324mm x 162mm x 2mm - Internal Plate With Oval Cyl Hole & Pull Handle 267 X 17.5mm 20925NA/P4LSS 20925NA/P4RSS
