• Installation
    Easy to install. Supplied with detailed mounting instructions.

    Type
    Tubular Latch

    Handing
    Suitable for left and right handed doors.

    Materials
    Key in Lever: Zinc Alloy
    Chassis: Steel
    Bolt head: Zinc

    Fixing
    Horizontal mounting screw fixing.

    Door Thickness
    35 to 51mm for timber doors.

    Backset
    60 to 70mm adjustable latch standard.

    Latch
    13mm throw.

    Strike
    D-strike with anti-rattle tab as standard.

    Cylinder
    5 pin Lockwood C4 brass cylinder assembly (6 pin compatible).

    Functions
    Entrance, privacy, passage and dummy available.

    Keying

    Standard Keying

    • Supplied individually keyed with three keys per lock
    • 78,000 key combinations
    • Key blank KB2015P

    Restricted Special Keying

    Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different evels of mechanical access control.

    Lockwood Keying Platforms - more information

    Finishes

    • Everbrass EVB
    • Chrome Plate CP
    • Satin Chrome Brushed SC

    Packaging
    Trade pack only available.

    Dimensions


  • DescriptionPart numberBarcode
    TRADE PACK
    Entrance Set, Everbrass¨ (Lifetime Finish Warranty)7540EVB93-11847-78745-2
    Entrance Set, Chrome Plate7540CP93-11847-78744-5
    Entrance Set, Satin Chrome Plate7540SC93-11847-78746-9
    Passage Set, Chrome Plate7541CP93-11847-78725-4
    Passage Set, Polished Brass7541PB93-11847-78723-0
    Passage Set, Satin Chrome Plate7541SC93-11847-78724-7
    Privacy Set, Chrome Plate7542CP93-11847-78728-5
    Privacy Set, Polished Brass7542PB93-11847-78726-1
    Privacy Set, Satin Chrome Plate7542SC93-11847-78727-8
    Left Handed Dummy - Lh, Dummy, Chrome Plate7545LCP93-11847-78731-5
    Left Handed Dummy - Lh, Dummy, Polished Brass7545LPB93-11847-78729-2
    Left Handed Dummy - Lh, Dummy, Satin Chrome Plate7545LSC93-11847-78730-8
    Right Handed Dummy - Rh, Dummy, Chrome Plate7545RCP93-11847-78734-6
    Right Handed Dummy - Rh, Dummy, Polished Brass7545RPB93-11847-78732-2
    Right Handed Dummy - Rh, Dummy, Satin Chrome Plate7545RSC93-11847-78733-9
