• Installation
    Easy to install. Supplied with detailed mounting instructions.

    Handing
    Suitable for left and right handed doors.

    Materials
    Knob – Stainless Steel and Brass
    Type: Cylindrical
    Chassis: Steel
    Bolt head: Stainless steel

    Fixing
    Vertical mounting screw fixing.
    Fixing concealed with snap-on trim.

    Door Thickness
    32 to 46mm for timber doors.

    Backset
    60mm cylindrical latch standard.

    Latch
    13mm throw.

    Strike
    D-strike with anti-rattle tab as standard.

    Cylinder
    5 pin Lockwood C4 brass cylinder assembly (6 pin compatible).

    Fire Rating
    Lockwood Symmetry Furniture has been successfully fire tested up to 2 hours (depending on the type of fire door) on fire door assemblies, in accordance with Australian Standard AS 1905.1 – 1997, Part 1: Fire Resistant Doorsets.

    Functions
    Entrance, privacy, passage and dummy available.

    Keying

    Standard Keying

    • Supplied individually keyed with three keys per lock
    • 78,000 key combinations
    • Key blank KB2015P

    Restricted Special Keying

    Lockwood locks can be keyed to a number of controlled and/or specially keyed systems. These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

    Lockwood Keying Platforms - more information

    Finishes

    • Everbrass EVB
    • Polished Stainless Steel PSS
    • Satin Stainless Steel SSS

    Dimensions


  • Description (Trade Pack)Part numberBarcode
    Cylindrical Key In Knob Locksets - Entrance Set, Polished Stainless Steel7020PSS93-11847-50860-6
    Cylindrical Key In Knob Locksets - Entrance Set, Satin Stainless Steel7020SSS93-11847-47697-4
    Cylindrical Key In Knob Locksets - Passage Set, Polished Brass7021PB93-11847-47710-0
    Cylindrical Key In Knob Locksets - Passage Set, Polished Stainless Steel7021PSS93-11847-51073-9
    Cylindrical Key In Knob Locksets - Passage Set, Satin Stainless Steel7021SSS93-11847-47711-7
    Cylindrical Key In Knob Locksets - Privacy Set, Polished Brass7022PB93-11847-47703-2
    Cylindrical Key In Knob Locksets - Privacy Set, Polished Stainless Steel7022PSS93-11847-51074-6
    Cylindrical Key In Knob Locksets - Privacy Set, Satin Stainless Steel7022SSS93-11847-47704-9
    Cylindrical Key In Knob Locksets - Dummy Knob, Polished Brass7025PB93-11847-47717-9
    Cylindrical Key In Knob Locksets - Dummy Knob, Polished Stainless Steel7025PSS93-11847-51075-3
    Cylindrical Key In Knob Locksets - Dummy Knob, Satin Stainless Steel7025SSS93-11847-47718-6
