• Voltage
    12Vdc

    Current
    175 mA @ 12Vdc

    Solenoids
    Solenoids are rated for continuous use

    Monitoring
    Solenoid Monitor - 1 amp NO/NC microswitch
    Door/Latch Monitor - 1 amp NO/NC microswitch

    Holding Force
    850kg Static Strength Rating

    Endurance
    Cycle tested to 1,000,000 operations

    Latch
    Suitable for 15mm latch bolt with 3mm door gap

    Environment
    Operational temperature range - 20°C to +60°C

    Body
    Solid Stainless Steel Construction

    Keeper
    Stainless Steel

    Specification Statement
    The strike should be constructed of solid stainless steel, have a minimum holding force of 850kg and have an endurance rating of 1 million cycles. Monitoring must include independent door / latch& solenoid monitoring. The one strike must be changeable from fail safe to fail secure on site where required. The strike should not consume current greater than 175mA at 12Vdc and have a solenoid rated for continuous use. Certifications must include CE, C-Tick and 4 hr fire rating.

     Dimensions



  • Description (Trade Pack)Part number
    ES2000 E/Strike 12Vdc Fail Safe MonitoredES2000-1
    ES2000 E/Strike 12Vdc Fail Secure MonitoredES2000-2
    Accessories - 13mm Rebate Plate210100-541
    Accessories - Mounting Kit220200-519
    Note: If Extension Lips are required, use ES2100 Electric Strike (Refer to catalogue)
