NEWSES9100 Series Pre-load Strike with Door Position Monitoring
ES9100 Series Pre-load Strike with Door Position Monitoring
2023-10-11
2 min read
ASSA ABLOY Opening Solutions Australia is pleased to announce the release of the Lockwood ES9100 Electric Strike. Meticulously designed and assembled in Australia, the new ES9100 Electric Strike introduces a host of additional features and enhanced functionalities that will benefit both the installer and project application.
Unmatched Performance and Full Compatibility with ES9000 Electric Strike Specifications
The ES9100 utilises the same footprint and contains all the specifications of the ES9000 Electric Strike, including the ability to operate with up to 25kg’s of Pre-Load pressure on the Keeper, and standard electric strike monitoring for lock status and latch position.
Integrated Door Position Monitoring for Seamless Security Integration, Eliminating the Need for Additional Hardware
What sets the ES9100 apart is the inclusion of Door Position Monitoring via an integrated Reed Switch. By including door position monitoring, the ES9100 can provide a more secure and complete integration with the access control system, without the need for the wiring and installation of additional monitoring hardware.
Features
- Operates under pre load up to 25kg
- Door Position Monitoring Output
- Lock Status and Latch Position Monitoring Output
- Easy field selectable fail safe/fail secure
- Multi voltage 10-30VDC
- 1300kg holding force
- 2.5 million cycles endurance rating
- Latch keeper is significantly quieter in operation
- Weather resistant (IP54)
- Pre-Drilled for Extension Lips
- Mounting tabs included
- Non handed
- 5 Year Tricare Warranty (Padde Series)
- Built in Protection Diode
Applications
- High traffic areas
- Doors subjected to side load (pre load)
- Fire rated door sets
- Inward and Outward opening doors
- Suitable for use with Access Control, Intercom, Keypad and Card Reader systems and doors requiring door position Monitoring
Ordering Information
| Part Number | Description |
| ES9100 | Lockwood ES9100 Electric Strike, 10-30VDC, Preload, Door Position Monitoring, Ext Lip Holes |
Note: all ES9100 series electric strikes are supplied in Fail Safe (PTL) configuration
Accessories
| Part Number | Description |
| SP3570-2100SSS | Magnet Faceplate to suit 3570 Series Mortice Lock – Timber door |
| 3772-2100SS | Magnet Faceplate to suit 3770 Series Mortice Lock – Timber door |
| 3772AF-2100SS | Magnet Faceplate to suit 3770 Series Mortice Lock – Aluminium door |
| 3782-2100SS | Magnet Faceplate to suit 3782 Series Mortice Lock – Aluminium door |
| 210100-541 | 13mm Rebate Plate |
| 220200-505 | 25mm Extension Lip (40.5mm total) |
| 220200-506 | 50mm Extension Lip (65.5mm total) |
| 220200-507 | 75mm Extension Lip (90.5mm total) |
This solution will also be available to the export market under the Trimec brand. Click here for more information.
